Aperture Shape Optimization for Electroplating of a Printed Circuit Board
Application ID: 139551
An aperture is often used in electroplating baths in order to improve the uniformity of the deposited metal layer.
This example simulates electroplating of a printed circuit board (PCB) in 3D using a secondary current distribution. The size and aspect ratio of the aperture is optimized using the Shape Optimization interface.
